Contoil DN 15- 50 Fuel oil meter

A versatile flow meter for oil, heavy oil and many other oil-like liquids. It is used for efficient consumption measurement of heat burners and various combustion engines. A reliable solution for any application where oil is consumed.

Category: Tag:

Features

  • State-of-the-art design
  • Electronic counter, mass flow, volume flow indication, multiple output signals
  • Integrated temperature sensor
  • No straight inlets or outlets required
  • Independent of viscosity and temperature
  • High vibration resistance
  • Optional: metrological type approval
  • Automatic medium switch based on temperature

Benefits

  • Mass flow measurements
  • Highly flexible mounting with very small space requirements
  • Reliable monitoring and flexible control of the system
  • Accurate measurements
  • A reliable solution with everything from a single supplier
  • Simplifies consumption optimizing

OPERATING PRINCIPLE

Function

CONTOIL® fuel oil meters work on the volumetric principle of rotary piston meters (positive displacement meters). The main features of this measuring principle are large measuring ranges, high accuracy, suitability for high viscosities and independence from power supply.

Flow disturbances do not influence proper operation

PRODUCT RANGE

CONTOIL® fuel oil meters DN 15 – 50

Hydraulic
CONTOIL® one hydraulic with multiple combination possibilities (display options)

Housing with threaded (RC) or flanged (FL) connection

Main characteristics:

  • Optimal flow range 20 – 30 000 l/h
  • Temperature ranges 130 and 180 °C
  • Nominal pressure PN 16, 25 and 40 bar

CONTOIL® ® VZF/A II with multifunctional
display and adjustable outputs

Hydraulic
CONTOIL® one hydraulic with multiple combination possibilities (display options)

Housing with threaded (RC) or flanged (FL) connection

Output signals for electronic display:

  • Volume and mass pulses
  • Actual flow rate and mass flow
  • Temperature display
  • Limiting values (Qmin, Qmax)
  • Status switch (alarm, error)
  • External power supply (4 – 20 mA 2 wire current loop)
  • Simple to operate

CONTOIL® VZO/A total volume display

Total volume display on roller counter

CONTOIL® VZO/A RV/IN total volume display and remote transmission

    Total volume display on roller counter with

  • Reed pulse (RV) for remote totalization
  • Inductive pulse (IN) for control purposes

CONTOIL® DFM compact design for remote display transmission

Pulse value for remote totalizing
